Omron FQ2-S Series User Manual

Controlling Operation and Outputting Data with EtherNet/IP Communications
FQ2-S/CH User’s Manual
for Communications Settings
93
3
Controlling Operation and Outputting Data with an
Ethernet Connection
Parameter Description Setting range
Output handshake Set whether to synchronize with the PLC when
data is output.
No: Measurement results are output without
synchronizing with the PLC.
Data Output after Measurements
When Handshaking Is Disabled: p. 117
Yes: Measurement results are output while syn-
chronizing with the PLC.
Data Output after Measurements
When Handshaking Is Enabled: p. 117
•Yes
•No
(default: Yes)
Output data size Set the data size to output from the output area.
Any changes in the setting are applied when
the Sensor is restarted.
Output Data Size and Number of Out-
put Data Upper Value Setting: p. 25
Set the input connection (input tag set) to 16
bytes greater than the size that you set for this
parameter.
32 bytes, 64 bytes, 128 bytes, or 256 bytes
(default: 32 bytes)
Note
If the total size of the data that is specified as
output data exceeds the size that is set here,
all of the data will not be output at the same
time, but will be separated over more than one
cycle.
Important
