Control Methods Using an External Device
FQ2-S/CH User’s Manual
for Communications Settings
25
1
Overview of Communication Specifications
Output Data Size and Number of Output Data Upper Value Setting (EtherNet/IP, PLC Link, PROFINET)
When more than one inspection result is output, the size of the data that is output for the data output settings
could exceed the limit that is set in the [Max output data] (number of output data upper value) parameter
setting.
If that occurs, increase the set value of the number of output data upper value setting or adjust the output data
settings so that data output size is not exceeded.
If the size of the data that is output exceeds the data size that can actually be output (output data limit), the
remaining data is handled as follows in each communication protocol.
• EtherNet/IP, PROFINET: The remaining data is divided and output over several cycles.
• PLC Link: The remaining data is discarded.
Example
Output data size: 328 bytes
Number of output data upper value setting: 256 bytes
Data Output Settings
Data 0
Output data Setting
Data 1
Data 2
I0.X[0] Inspection item 0: Position X for Search
I0.Y[0] Inspection item 0: Position Y for Search
LPC
(0,30,I1.X,I1.Y)
Inspection item 1: Position X 1st point for Shape Search II
Inspection item 1: Position X 30th point for Shape Search II
Inspection item 1: Position Y 1st point for Shape Search II
Inspection item 1: Position Y 30th point for Shape Search II
Data 3 LPR
(0,10,I2.X,I2.Y)
Inspection item 2: Position X 1st point for Shape Search II
Inspection item 2: Position Y 1st point for Shape Search II
Inspection item 2: Position X 10th point for Shape Search II
Inspection item 2: Position Y 10th point for Shape Search II
328
bytes
