Omron FQ2-S Series User Manual

Control and Output in No-Protocol (TCP) / No-Protocol (UDP)
FQ2-S/CH User’s Manual
for Communications Settings
173
3
Controlling Operation and Outputting Data with an
Ethernet Connection
• When Output Format Is ASCII
Set the parameters for integer digits, decimal digits, negative numbers, 0 suppression, the field separator, and
the record separator.
• Output Format
Example: Integer digits: 5, decimal digits: 3, negative number expression: −, zero suppressed: none, field
separator: comma, record separator: CR
*1 Because the record separator is set to CR, only one record is output for each measurement. A blank line (CR: delimiter) will therefore be
entered after the record separator. If you do not want a blank line, set the record separator to None.
The following range of values can be output.
−999,999,999.9999 ≤ Measured value ≤ 999,999,999.9999
If the measured value is lower than −999,999,999.9999, then −999,999,999.9999 is output.
If the measured value is higher than 999,999,999.9999, then 999,999,999.9999 is output.
The following values are output if JG (Judge) is set.
OK: 0
NG: −1
Item Description Setting range
For ASCII Digits of inte-
ger
Sets the number of digits in the integer part of
the number.
1 to 10 digits
Default: 6 digits
Digits of dec-
imal
Set the number of digits in the integer part. 0 to 4 digits
Default: 4 digits
Negative
Sets the way to express negative numbers. − or 8
Default: −
0 Sup-
pressed
Sets whether to use zero suppression. Yes or No
Default: No
Field sepa-
rator
Sets the field separator. OFF, comma, tab, space, CR, LF, or
CR+LF
Default: OFF
Record sep-
arator
Sets the record separator. OFF, comma, tab, space, CR, LF, or
CR+LF
Default: OFF
For Binary Decimal out-
put form
Set the decimal output form for numerical data. Floating point or fixed point (default:
Fixed point)
Measured value of
data 0
,
Measured value of
data 1
,· · ·
Measured value of
data 7
CR
The data output method, digits, and data separators can be changed as needed.
The field separator is not output unless the data continues.
Note
1
Measured value of data 0
1221123345 567 6 6 65 65 CR 998 7778.. . .,, ,,
Measured value
of data 1
Measured
value of data 7
Measured
value of data 2
Field separator Record separator
*1
Delimiter
Field separator
Field separator
Field separator
CR
Note
