Command Control
254
FQ2-S/CH User’s Manual
for Communications Settings
Save All Image Data
This command saves all image data saved in the Sensor's memory by the logging function to the SD card
inserted in the Touch Finder as ifz data.
The backup data destination and file name are fixed as follows.
• Destination
The following fixed directory on the SD card.
\Sensor name\LOGIMAGE\Number
*
*Number is a five digit number starting from 00000. The images are saved in increments of 100 images for each number, and when there
are over 100 images, the directory with the next number is created.
The file name is not case sensitive. The file name extension can be omitted.
•File name
Automatically created as follows.
img_ScnNNN_YYYY_MM_DD-HH_mm_ss(S)_TTTT_XX.ifz
*1 The date and time are not recorded in the image data. Therefore, this is not the date and time that the measurement was performed, this is
the date and time the image data file was saved from the Sensor to the Touch Finder SD card by this command.
For example, when performing the 10th measurement with scene 1 after the Sensor's power supply has been turned on, and the execution
time of this command is December 5, 2013, at 22:10:21
img_Scn001_2013_12_05-22_01_21(1)_10_OK.ifz
Command (PLC to Vision Sensor)
Response (Vision Sensor to PLC)
img Prefix string. The string can be set as desired with the following setting.
(Setup Mode or Run Mode) − [TF settings] − [File format]
ScnNNN Scn + measured scene number (0 to 31)
YYYY_MM_DD Date that the image data was saved to the Touch Finder SD card
*1
HH_mm_ss Time that the image data was saved to the Touch Finder SD card
*1
(S) Image data number (0 to 19)
TTTT Number of measurements since the Sensor was started. Reset when the power supply is
turned OFF.
XX Total judgment (OK/NG)
First word of com-
mand area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0100 0000 0001 0000 Command code
+3 0000 0000 0111 0000
First word of
response area
Bits Contents
12 to 15 8 to 11 4 to 7 0 to 3
+2 0100 0000 0001 0000 Command code
Response target command codes
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
