Omron FQ2-S Series User Manual

Command Control
256
FQ2-S/CH User’s Manual
for Communications Settings
Save Calibration Data
Saves the data for the specified calibration number as a file to the SD card inserted in the Touch Finder.
The destination for scene data is the following fixed directory on the SD card.
\Sensor name\CLB
The file name is not case sensitive. The file name extension can be omitted.
Command (PLC to Vision Sensor)
*1 Saved as a file named Calibration_***.clb. (***: Specified file number)
Response (Vision Sensor to PLC)
First word of
command
area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1010 0000 0000 0000 Command code
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 Calibration number to save
+5 0000 0000 0000 0000
+6 0000 0000 0000 0000 • EtherNet/IP,
PROFINET
File number to
save (0 to 999)
*1
• PLC link
File name to
load
64 characters
max.
The file name
extension (.clb)
can be omitted.
+7 0000 0000 0000 0000
+8 0000 0000 0000 0000 ---
: ::::
+37 0000 0000 0000 0000
First word of
response area
Bits
Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1010 0000 0000 0000 Command code
The command code for which the
response applies is stored.
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
