Command Control
258
FQ2-S/CH User’s Manual
for Communications Settings
Save Model Dictionary Data
Saves the specified number of model dictionary data as a file to the SD card inserted in the Touch Finder.
The destination for scene data is the following fixed directory on the SD card.
\Sensor name\DIC
The file name is not case sensitive. The file name extension can be omitted.
Command (PLC to Vision Sensor)
*1 Saved as a file named Dictionary_***.dic. (***: Specified file number)
Response (Vision Sensor to PLC)
First word of
command
area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1100 0000 0000 0000 Command code
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 Model dictionary data number to
save
+5 0000 0000 0000 0000
+6
0000 0000 0000 0000 • EtherNet/IP,
PROFINET
File number to
save (0 to 999)
*1
• PLC link
File name to
load
64 characters
max.
The file name
extension (.dic)
can be omitted.
+7
0000 0000 0000 0000
+8
0000 0000 0000 0000 ---
:
::::
+37
0000 0000 0000 0000
First word of
response area
Bits Description
12 to 15 8 to 11 4 to 7 0 to 3
+2 1100 0000 0000 0000 Command code
The command code for which the
response applies is stored.
+3 0000 0000 0111 0000
+4 0000 0000 0000 0000 Response code
Command execution result
0: OK, FFFFFFFF: NG
+5 0000 0000 0000 0000
