Omron FQ2-S Series User Manual

Detailed EtherNet/IP Communications Specifications
434
FQ2-S/CH User’s Manual
for Communications Settings
1-2 02h Message Router Object
Class Attributes
None
Instance Attributes
None
Services
None
1-3 06h Connection Manager
Class Attributes
None
Instance Attributes
None
Services
1-4 F5h TCP/IP Interface
Class Attributes
Instance Attributes
Code Service name Class Instances Remarks
54 hex Forward Open No Yes
4E hex Forward Close No Yes
ID Access Name Data type Description Attribute value
1 Get Revision UINT Revision of the object 1
2 Get Max Instance UINT Maximum instance number 1
3 Get Num Instance UINT Number of object instances 1
ID Access Name Data type Description Attribute value
1 Get Status DWORD Interface status 0x0002 (Depends
on the device.)
2 Get Configuration Capability DWORD Interface Function Flag 0x0002 (Depends
on the device.)
3 Get/Set Configuration Control DWORD Interface Control Flag 0x0000
FQ2-S_CH_comm.book 434 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
