Omron GX-ILM08C User Manual

A - 39
A Appendix
GX-series EtherCAT Slave Unit User’s Manual
A-1 Object Dictionary
A
A-1-7 Manufacturer Specific Objects
 Device Profile area
• Digital input values are stored in units of 1 byte (8 bits).
• It is implemented in all Slave Units with input points (including Expansion Units if they are
connected).
• Digital input values are stored in units of 2 byte (16 bits).
• Digital input values are stored in units of 4 byte (32 bits).
6000 hex Read input 8bit
Sub-index 0: Number of inputs 8bit
Range: 00 hex to 04 hex Unit: − Default: Differ by Slave Unit types* Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Read input 1st byte
Range: 00 hex to FF hex Unit: − Default: − Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible*
Sub-index 2: Read input 2nd byte
Range: 00h to FFh Unit: − Default: − Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 3: Read input 3rd byte
Range: 00 hex to FF hex Unit: − Default: − Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 4: Read input 4th byte
Range: 00 hex to FF hex Unit: − Default: − Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
6100 hex Read input 16bit
Sub-index 0: Number of inputs 16bit
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Read input 1st word
Range: 0000 hex to FFFF hex Unit: − Default: − Attribute: −
Size: 2 bytes (U16) Access: RO PDO map: Possible
6120 hex Read input 32bit
Sub-index 0: Number of inputs 32bit
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Read input 1st double word
Range: 00000000 hex to
FFFFFFFF hex
Unit: − Default: − Attribute: −
Size: 4 bytes (U32) Access: RO PDO map: Possible
