Omron H5F User Manual

■H5F-B (Flush-mounting Model )
■H5F-FB (Surface-mounting Model)
●Dimensions ●MountingDimensions
●Dimensions ●MountingDimensions
- 29 -
Installation
Y92A-48DustCover(soldseparately)
R0.5max
Note:
Payattentiontothe
orientationoftheadapter
whenmountingtwoormore
timeswitchesinavertical
orhorizontal.
Panel
Y92F-30
Flush-mounting 
Adapter(accesory)
Y92A-48EDustCover(soldseparately)
Cutoutsections:
(Cut out as required
for wiring.)
Terminal cover
(accesory)
M4tappingscrews(2;provided)
Mountingspace
<Sizeoftappingscrewhole>
Thicknessofapanel Sizeofhole
0.8 to 1.2mm ø3.6mm
1.6 to 4.0mm ø3.7mm
1. Dimensions and Mounting Dimensions
[mm]
[mm]
Terminal cover
(accesory)
48
63.7
84.8
88.7
614
48
37.7
□
50.6
□
44.8
48
45
+0.5
0
45
+0.5 0
58
50
49
31
42.1
50
92 76
(50)
1.5
(92)
76 8
