Omron J1000 System Configuration

J1000 11
A Line filters
A Chokes
B Communication cards
C Accessories
D Computer software
E Braking unit, braking resistor unit
Inverter Line filter Schaffner
Line filter Rasmi
Voltage Model JZA@ Reference Rated current (A) Weight (kg) Reference Rated current (A) Weight (kg)
3-Phase
200 VAC
20P1 / 20P2 / 20P4 / 20P7 A1000-FIV2010-SE 10 0.7 A1000-FIV2010-RE 10 0.8
21P5 / 22P2 A1000-FIV2020-SE 20 0.9 A1000-FIV2020-RE 20 1.1
24P0 A1000-FIV2030-SE 30 1.0 A1000-FIV2030-RE 30 1.3
Single-Phase
200 VAC
B0P1 / B0P2 / B0P4 A1000-FIV1010-SE 10 0.5 A1000-FIV1010-RE 10 0.6
B0P7 / B1P5 A1000-FIV1020-SE 20 0.7 A1000-FIV1020-RE 20 1.0
3-Phase
400 VAC
40P2 / 40P4 A1000-FIV3005-SE 5 0.5 A1000-FIV3005-RE 5 1.1
40P7 / 41P5 / 42P2 / 43P0 A1000-FIV3010-SE 10 0.75 A1000-FIV3010-RE 10 1.1
44P0 A1000-FIV3020-SE 15 1.0 A1000-FIV3020-RE 20 1.3
Model Diameter Description
A1000-FEV2102-RE 21
Recommended for motors below 2.2 KW
A1000-FEV2515-RE 25
Recommended for motors below 15 KW
Type Model Description Function
Option units
SI-232/JC RS-232C serial communication interface
• RS232C communications interface to connect the drive to a PC or the
optional copy unit
SI-232/J Remote operator interface
• RS232C communication interface for usage with the external LED
operator JVOP-182
SI-485/J
RS-422/485 Serial
communications interface
• Interface for RS-422/485 communications using the MEMOBUS/
Modbus RTU protocol
AI-V3/J Potentiometer Option
• Potentiometer option for setting the frequency reference directly at the
drive
Types Model Description Functions
Digital
operator
JVOP-182 LED remote operator Remote operator with LED display and copy function, cable length max. 3m.
A1000-CAVOP300-EE Remote operator cable 3 meters cable for connecting remote operator
Accessories
JVOP-181 USB converter / USB cable
Allows the user to copy and verify parameter settings between drives. Can
also be used as adapter to connect the drive to a PC USB port. SI-232/JC
option is required
A1000-CAVPC232-EE PC connection cable RS232 PC tool connection cable
Types Model Description Installation
Software
CX-drive Computer software Configuration and monitoring software tool
CX-One Computer software Configuration and monitoring software tool
Inverter Braking resistor unit
Voltage
Max.
applicable
motor
output kW
Inverter model JZA@
Connectable min.
resistance Ω
Inverter-mounted type (3 %ED, 10 sec max)
3-phase 1-phase Type Resistance Ω No. of used Braking torque %
200 V
(single-/
three-phase)
0.12 20P1 B0P1 300
A1000-REJ0K15400-IE 400 1
220
0.25 20P2 B0P2 300 220
0.55 20P4 B0P4 200
A1000-REJ0K15200-IE 200 1
220
1.1 20P7 B0P7 120 125
1.5 21P5 B1P5 60 A1000-REJ0K15100-IE 100 1 125
2.2 22P2 - 60 A1000-REJ0K15070-IE 70 1 120
4.0 24P0 - 32 A1000-REJ0K15062-IE 62 1 100
400 V
(three-phase)
0.37 40P2 – 750
A1000-REJ0K10750-IE 750 1
230
0.55 40P4 – 750 230
1.1 40P7 – 510 130
1.5 41P5 – 240 A1000-REJ0K15400-IE 400 1 125
2.2 42P2 – 200 A1000-REJ0K15300-IE 300 1 115
3.0 43P0 –
100 A1000-REJ0K15400-IE 400 2 105
4.0 44P0 –
