2 Frequency inverters
Type designation
200 V class
400 V class
Specifications
Single-phase: JZA@ B0P1 B0P2 B0P4 B0P7 B1P5 - -
Three-phase: JZA@ 20P1 20P2 20P4 20P7 21P5 22P2 24P0
Motor
kW
1
1. Based on a standard 4-pole motor for maximum applicable motor output:
Heavy Duty (HD) mode with a 150% overload capacity
Normal Duty (ND) mode with a 120% overlaod capacity
For HD setting 0.12 0.25 0.4 1.1 1.5 2.2 4.0
For ND setting 0.18 0.37 0.55 1.1 2.2 3.0 5.5
1
Output
characteristics
Inverter capacity kVA
0.3 0.6 1.1 1.9 3.0 4.2 6.7
Rated output current (A) at HD
0.8 1.6 3.0 5.0 8.0 11.0 17.5
Rated output current (A) at ND
1.2 1.9 3.5 6.0 9.6 12.0 21.0
Max. output voltage
Proportional to input voltage: 0..240 V
Max. output frequency
400 Hz
Power
supply
Rated input voltage
and frequency
Single-phase 200..240 V 50/60 Hz
3-phase 200..240 V 50/60 Hz
Allowable voltage
fluctuation
-15%..+10%
Allowable frequency
fluctuation
+5%
Three-phase: JZA@
40P2 40P4 40P7 41P5 42P2 43P0 44P0
Motor
kW
1
1. Based on a standard 4-pole motor for maximum applicable motor output:
Heavy Duty (HD) mode with a 150% overload capacity
Normal Duty (ND) mode with a 120% overlaod capacity
For HD setting 0.37 0.55 1.10 1.5 2.2 3.0 4.0
For ND setting 0.37 0.75 1.5 2.2 3.0 4.0 5.5
Output
characteristics
Inverter capacity kVA
0.9 1.4 2.6 3.7 4.2 5.5 7.2
Rated output current (A) at HD
1.2 1.8 3.4 4.8 5.5 7.2 9.2
Rated output current (A) at ND
1.2 2.1 4.1 5.4 6.9 8.8 11.1
Max. output voltage
0..480V (proportional to input voltage)
Max. output frequency
400 Hz
Power
supply
Rated input voltage
and frequency
3-phase 380..480 VAC, 50/60 Hz
Allowable voltage
fluctuation
-15%..+10%
Allowable frequency
fluctuation
+5%
