Omron J1000 System Configuration

4 Frequency inverters
IP 20 type 0.1 to 4 kW
Schaffner footprint Filters
Dimensions
Voltage class
Max. applicable
motor output kW
Inverter model JZA@ Figure
Dimensions in mm
W1 H1 W H D t1 H2 D1 D2 Weight
Single-phase
200 V
0.12 B0P1
156
118
68
128
76 3
5
6.5 67.5
0.6
0.25 B0P2 0.6
0.55 B0P4 118
5
38.5 109.5 1.0
1.1 B0P7
296 108
137.5
58
129 1.7
1.5 B1P5 154 145.5 1.8
Three-phase 200
V
0.12 20P1
156
118
68
128
76 3
5
6.5 67.5
0.6
0.25 20P2 0.6
0.55 20P4 108
5
38.5
99.5 0.9
1.1 20P7 128 119.5 1.1
1.5 21P5
2
96 108
129
58
120.5 1.7
2.2 22P2 137.5 129 1.7
4.0 24P0 128 140 143 65 134.5 2.4
Three-phase
400 V
0.37 40P2
2
96
118
108
128
81
55
10 72.5 1.0
0.55 40P4 99 28 90.5 1.2
1.1 40P7 137.5
58
129 1.7
1.5 41P5
154 145.5
1.7
2.2 42P2 1.7
3.0 43P0 1.7
4.0 44P0 128 140 143 65 134.5 2.4
Schaffner model
Dimensions
Weight
KG
A B C D E F G H I J K L
3x200 V
A1000-FIV2010-SE 194 82 50 160 181 62 5.3 M5 25 56 118 M4 0.40
A1000-FIV2020-SE 169 111 50 135 156 91 5.5 M5 25 96 118 M4 0.58
A1000-FIV2030-SE 174 144 50 135 161 120 5.3 M5 25 128 118 M4 0.90
1x200 V
A1000-FIV1010-SE 169 71 45 135 156 51 5.3 M5 22 56 118 M4 0.44
A1000-FIV1020-SE 169 111 50 135 156 91 5.3 M5 25 96 118 M4 0.75
3x400 V
A1000-FIV3005-SE 169 111 45 135 156 91 5.3 M5 22 96 118 M4 0.5
A1000-FIV3010-SE 169 111 45 135 156 91 5.3 M5 22 96 118 M4 0.7
A1000-FIV3020-SE 174 144 50 135 161 120 5 M5 25 128 118 M4 0.9
Figure 1
Figure 2
t1
D
D1
4-M4
H
W1
W
H2 H1
D2
t1
D1
D
W
H1H2
H
2-M4
W1
D2
