Appendix D
Available Parameters
Available parameters vary with the output board of the K3NX and are indicated as “YES” in the following table.
Setting Mode
Menu Parameter
Output Board
No
output
C1/C2
/C5/T1
/T2
B2 B4 L1/
L2/
L3/L7/
L8
L4/L5/
L6/L9/
L10
FLK1/
FLK2/
FLK3
FLK4/
FLK5/
FLK6
sUset
Setting
values
sU.hh HH set value
YES
(note
1)
YES YES YES
menu
sU. h H set value
YES YES YES YES
sU. l L set value
YES YES YES YES
sU.ll LL set value
YES
(note
1)
YES YES YES
scale
inp.2 Input value 2
YES YES YES YES YES YES YES YES
Scaling
dsp.2 Display value 2
YES YES YES YES YES YES YES YES
menu
inp.1 Input value 1
YES YES YES YES YES YES YES YES
dsp.1 Display value 1
YES YES YES YES YES YES YES YES
decĆp Decimal point position
YES YES YES YES YES YES YES YES
setup
inĆt Input range
YES YES YES YES YES YES YES YES
Setup menu
fre Power supply frequency
YES YES YES YES YES YES YES YES
uĆno Communications unit no.
YES YES
bps Baud rate
YES YES
len Word length
YES YES
sbit Stop bits
YES YES
prty Parity bits
YES YES
opt
aUg Average processing
YES YES YES YES YES YES YES YES
Option
stine Startup compensation time
YES YES YES YES YES YES YES YES
menu
hys Hysteresis
YES YES YES YES
cĆout Comparative output pattern
YES YES YES YES
lset.h H linear output range
YES
(note
2)
YES
(note
2)
lset.l L linear output range
YES
(note
2)
YES
(note
2)
rĆl Remote or local
programming
YES YES
test
Output test
YES YES YES YES YES YES YES
Note 1. The HH and LL set values cannot be set with the K31-C1 Output Board.
2. The linear output range cannot be set with K31-L3 and K31-L6 Output Boards.
