LD Cart Transporter User's Guide, 14766-000 Rev B
Page 108 of 190
Chapter 6: Connectivity
Batt Comm.
Connector type Mini-Fit
®
3 x 2
Use Battery control
Pin No. Designation Notes
1 GND
Connections to the
Factory-Supplied Battery
2 RS232_BATT_RXD
3 RS232_BATT_TXD
4 FBAT_ALWAYS
5 START_BUTTON
6 OFF_BUTTON
