LD Cart Transporter User's Guide, 14766-000 Rev B
Page 159 of 190
Chapter 10: Maintenance
2.
Press the left (front) side of the panel in, and the latch will hold it.
This is a toggle latch - pressing it once engages it, pressing it a second time releases it.
Rear Inner (Battery) Cover
1.
Slide the cover up, so its top tab fits under the rear outer cover.
CAUTION: Pinch hazard. This cover is the most likely to pinch you if
you are not careful, particularly at its bottom edge. Hold the cover at the
bottom, in the center, with two hands.
2.
Holding the cover near the center, with both hands, tilt the bottom of the cover down,
towards the platform chassis.
10.7 Replacing Periodic Parts
The drive motors and gearbox are sealed and permanently lubricated, so they do not require
periodic maintenance.
Battery Replacement
The battery is expected to last for approximately 7 years of 16 hours/day, 5 days/week. Life
expectancy for 19/7 is 4 years. (19 hours/day is full-time, with time-out to recharge.)
NOTE:There are no serviceable parts inside the battery case. Do not open it.
WARNING: Replace the battery only with an Omron Adept Technologies, Inc.
battery.
Dispose of the battery according to all local and national environmental regulations regarding
electronic components. Contact Omron Adept Technologies, Inc.
WARNING: Follow appropriate ESD procedures during the
removal/replacement phases.
Removal
WARNING: The battery is heavy (19 kg/42 lbs). Observe safe lifting
practices when removing or installing the battery.
1.
Remove the inner rear platform cover.
a.
Pull the bottom of the cover away from the platform chassis.
This is easiest if you grip it with two hands, toward the center.
