Chapter 10: Maintenance
A pinch point label is on top of the latch mechanism cover.
l
Hand-entanglement Label, 18180-000
A hand entanglement label is under the latch mechanism cover, near the belt and pul-
ley.
See Removing Latching Mechanism Cover on page 152 for instructions on removing
the cover.
l
Pacemaker, Magnetic Field Warning Label, 13306-000L
One magnetic field/pacemaker label is on the transporter rear cover.
A second is on the top rear bar of the cart.
A third is on the underside of the transporter, on the docking funnel. This magnet is
only exposed during maintenance, when the transporter is tipped on its side.
l
Yellow circle surrounding the E-Stop, 11229-167
This is labeled EMERGENCY STOP. It is located on the Operator Panel, at the top of the
HMI post.
l
No Riding Label, 18178-000
