LD Cart Transporter User's Guide, 14766-000 Rev B
Page 54 of 190
Chapter 3: Setup
Figure 3-22. Docking Station, Mounted on Floor Plate
406 [16.0]
495 [19.5]
Units are mm [in.]
Figure 3-23. Docking Station Floor Plate Dimensions
