LD Cart Transporter User's Guide, 14766-000 Rev B

Page 88 of 190

Chapter 6: Connectivity

Connector Designation Notes

J47 IN3 LEDDS29

J46 IN4 LEDDS28

JP6 RETURN Selects SINK LO or SOURCE HI

for J40, J45-47

J51 IN5 LEDDS33

J50 IN6 LEDDS32

J49 IN7 LEDDS31

J48 IN8 LEDDS30

JP7 RETURN Selects SINK LO or SOURCE HI

for J48 - J51

Pin No. Designation Notes

1 BATTERY 22-29 VDC, 0.4 A TOTAL

2 GND HI (BAT) or LO (GND)

3 SENSOR

4 SHIELD GND
