A-17
Appendices
NB-series Programmable Terminals Setup Manual(V107)
A-5 List of Models
App
A-4-5 Method for fabricating the cable for
connection to PC
 Units at the host side which can be connected using the serial port of the NB
Unit in the RS-422A mode through Host Link
*1: Connect using conversion cables (CPM2C-CN111 type or CS1W-CN114/118 type), the RS-232C adaptor
(CPM1-CIF01 type) or the RS-422A adaptor (CPM1-CIF11 type).
PLC Series
CPU Unit with built-in Host
Link function
CPU Unit that can be connected
through adding Host Link
Units/communication boards
Options required for
connection
CP Series CP1L-L14/L20/M30/M40/M60 CP1L-L14/L20/M30/M40/M60 CP1W-CIF11/CIF12
CP1H-X40/XA40/Y20 CP1H-X40/XA40/Y20 CP1W-CIF11/CIF12
CP1E-N30/N40/N60/NA20 CP1E-N30/N40/N60/NA20 CP1W-CIF11/CIF12
CP1L-EL20/EM30/EM40 CP1W-CIF11/CIF12
C Series C200HE-CPU11/32/42
C200HE-CPU11/32/42-Z
C200HG-CPU33/43/53/63
C200HG-CPU33/43/53/63-Z
C200HX-CPU34/44/54/64
C200HX-CPU34/44/54/64/65/85-Z
C200H-LK202-V1
C200HE-CPU32/42
C200HE-CPU32/42-Z
C200HW-COM03/06-V1
C200HG-CPU33/43/53/63
C200HG-CPU33/43/53/63-Z
C200HW-COM03/06-V1
C200HX-CPU34/44/54/64
C200HX-CPU34/44/54/64/65/85-Z
C200HW-COM03/06-V1
CPM1-10/20CDR-
+CPM1-CIF11
CPM1A-10/20/30/40CD-
+CPM1-CIF11
CPM2A-30/40/60CD-
+CPM1-CIF11
(When a peripheral port is connected)
CPM2C-10/20-
(*1)
CQM1H-CPU51/61 CQM1H-SCB41
CS Series CS1G-CPU42/43/44/45(-V1)
CS1H-CPU63/64/65/66/67(-V1)
CS1W-SCB41(-V1)
CS1W-SCU31(-V1)
CS1G-CPU42H/43H/44H/45H
CS1H-CPU63H/64H/65H/66H/67H
CS1W-SCB41(-V1)
CS1W-SCU31(-V1)
CJ1 Series CJ1G-CPU44/45 CJ1W-SCU31/41-V1
CJ1G-CPU42H/43H/44H/45H
CJ1H-CPU65H/66H/67H
CJ1W-SCU31/41-V1
CJ1M-CPU11/12/13/21/22/23 CJ1W-SCU31/41-V1
CJ2 Series CJ2M-CPU31/32/33/34/35 CP1W-CIF11/CIF12
CJ2M-CPU11/12/13/14/15
CJ2H-CPU64/65/66/67/68
(-EIP)
