Omron NB3Q-TW00B Setup Manual

Appendices
A-18
NB-series Programmable Terminals Setup Manual(V107)
 Units at the host side which can be connected using the Ethernet port of the
NB Unit
 Software related to the NB Unit
 Related connecting objects
Cable with connectors (NB Unit ↔ PLC)
PLC Series
CPU Unit with built-in Ethernet
communication function
CPU Unit that can be connected through
adding Ethernet Communication
Unit/optional communication board
Options
required for
connection
CP Series CP1L-L14/L20/M30/M40/M60 CP1W-CIF41
CP1H-X40/XA40/Y20 CP1W-CIF41
CP1E-N30/N40/N60/NA20 CP1W-CIF41
CP1L-EL20/EM30/EM40
CS Series CS1G-CPU42/43/44/45(-V1)
CS1H-CPU63/64/65/66/67(-V1)
CS1W-ETN21
CS1W-EIP21
CS1G-CPU42H/43H/44H/45H
CS1H-CPU63H/64H/65H/66H/67H
CS1W-ETN21
CS1W-EIP21
CS1H-CPU63/64/65/66/67(-V1) CS1W-ETN21
CS1W-EIP21
CS1H-CPU63H/64H/65H/66H/67H CS1W-ETN21
CS1W-EIP21
CJ1 Series CJ1G-CPU42H/43H/44H/45H
CJ1H-CPU65H/CPU66H
CJ1W-ETN21
CJ1W-EIP21
CJ1M-CPU11/12/13/21/22/23 CJ1W-ETN21
CJ1W-EIP21
CJ1H-CPU65H-R/66H-R/67H-R
CJ1H-CPU65H/CPU66H
CJ1W-ETN21
CJ1W-EIP21
CJ2 Series CJ2M-CPU31/32/33/34/35
CJ2M-CPU11/12/13/14/15 CJ1W-ETN21
CJ1W-EIP21
CJ2H-CPU64/65/66/67/68(-EIP)
Name Version Release Time Descriptions Remarks
NB-Designer V1.0X February 2012 HMI with model number
of NB5Q-TW00B and
NB7W-TW00B supported
OS: Windows XP (SP1 or higher)
Windows Vista/Windows 7 (32/64-bit)
The NB-Designer incorporates a
transmission program and a standard
system program specified for the NB-
Series Units. For download the
application programs, please access
your local Omron website, If local site
cannot be found, please access Omron
IA global site “http://www.ia.omron.com/ ”
at first and select the area where you
are.
V1.1X June 2012 HMI with model number
of NB5Q-TW01B and
NB7W-TW01B added
V1.2X August 2012 HMI with model number
of NB3Q-TW00B/TW01B
and NB10W-TW01B
added
Models Cable Length Object Unit Communications methods Specifications
XW2Z-200T 2m Units with 9-pin
connectors by
OMRON
Host Link
(RS-232C)
9-pin ↔9-pin
XW2Z-500T 5m
NB-RSEXT-2M 2m RS-422/485
Communication
Units by PLC
manufacturers
Host Link
(RS-422/485)
9-pin ↔5-wire
WWW.NNC.IR
