Before you Begin
40
Following serial printing parameters can be set-
Baud Rate - Supported Baud rates are 4800, 9600, 19.2K, 38.4K, 57.6K and
115.2K.
Parity - Can be None, Even or Odd.
Number of Bits - Can be 7 or 8.
Number of columns - Can be from minimum 1 to maximum 80.
Terminating character - Can be None, CR(Carriage Return), LF(Line Feed) or CR+LF.
Number of characters - Can be from minimum 1 to maximum 256.
to print
Click ‘Ok’ to set printer setting.
3. For PLC Communication
Protocol - User can select desired PLC from the list of available drivers. In the example shown above,
user has selected Omron Host Link at Com1.
