H Sequence Parameters (From Pn500)
Parame- Parameter
Explanation
Default
Unit Setting Restart
ter No. name
Digit
No.
Name Set-
ting
Explanation
setting
range power?
Pn500 Positioning
completion
range 1
Sets the range of positioning completed output 1 (INP1). 3 Com-
mand unit
0 to 250 ---
Pn501 Position
lock rotation
speed
Sets the number of rotations for position lock during speed
control.
10 r/min 0 to
10000
---
Pn502 Rotation
speed for
motor
rotation
detection
Sets the number of rotations for the Servomotor rotation
detection output (TGON).
20 r/min 1 to
10000
---
Pn503 Speed
conformity
signal
output width
Sets the allowable fluctuation (number of rotations) for the
speed conformity output (VCMP).
10 r/min 0 to 100 ---
Pn504 Positioning
completion
range 2
Sets the range for positioning completed output 2 (INP2). 3 Com-
mand unit
1 to 250 ---
Pn505 Deviation
counter
overflow
level
Sets the detection level for the deviation counter over alarm. 1024 x 256
command
unit
1 to
32767
---
Pn506 Brake
timing 1
Sets the delay from the brake command to the Servomotor
turning OFF.
0 x 10 ms 0 to 50 ---
Pn507 Brake
command
speed
Sets the number of rotations for outputting the brake
command.
100 r/min 0 to
10000
---
Pn508 Brake
timing 2
Sets the delay time from the Servomotor turning OFF to the
brake command output.
50 x 10 ms 10 to 100 ---
Pn509 Momentary
hold time
Sets the time during which alarm detection is disabled when
a power failure occurs.
20 ms 20 to
1000
---
Operation Chapter 4
