4-40
• Do not set 7 (always ON).
• If setting 8 (always OFF), when the alarm is cancelled, turn ON the power or reset the alarm using the
operation keys.
Pn50b.2 Input signal selection 2 –– PCL signal (forward rotation current limit) input terminal allocation
(All operation modes)
Setting
range
0 to F Unit --- Default
setting
5 Restart
power?
Yes
• Settings are the same as for Pn50A.1.
• If Pn50A.0 is set to 0, you cannot change the pin number. Settings 0 to 6 and 9 to F are disabled, and all
are set to CN1, pin 45 enabled by L input. Settings 7 and 8 are both enabled.
• To change the pin number, set Pn50A.0 to 1.
Pn50b.3 Input signal selection 2 –– NCL signal (reverse rotation current limit) input terminal allocation
(All operation modes)
Setting
range
0 to F Unit --- Default
setting
6 Restart
power?
Yes
• Settings are the same as for Pn50A.1.
• If Pn50A.0 is set to 0, you cannot change the pin number. Settings 0 to 6 and 9 to F are disabled, and all
are set to CN1, pin 46 enabled by L input. Settings 7 and 8 are both enabled.
• To change the pin number, set Pn50A.0 to 1.
Pn50C.0 Input signal selection 3 –– RDIR signal (rotation direction command) input terminal allocation
(internally-set speed control)
Setting
range
0 to F Unit --- Default
setting
8 Restart
power?
Yes
• Settings are the same as for Pn50A.1.
• If Pn50A.0 is set to 0, you cannot change the pin number. Settings 0 to F are all disabled.
• To change the pin number, set Pn50A.0 to 1.
Pn50C.1 Input signal selection 3 –– SPD1 signal (speed selection command 1) input terminal allocation
(internally-set speed control)
Setting
range
0 to F Unit --- Default
setting
8 Restart
power?
Yes
• Settings are the same as for Pn50A.1.
• If Pn50A.0 is set to 0, you cannot change the pin number. Settings 0 to F are all disabled.
• To change the pin number, set Pn50A.0 to 1.
Pn50C.2 Input signal selection 3 –– SPD2 signal (speed selection command 2) input terminal allocation
(internally-set speed control)
Setting
range
0 to F Unit --- Default
setting
8 Restart
power?
Yes
• Settings are the same as for Pn50A.1.
• If Pn50A.0 is set to 0, you cannot change the pin number. Settings 0 to F are all disabled.
• To change the pin number, set Pn50A.0 to 1.
Pn50C.3 Input signal selection 3 –– TVSEL signal (control mode switching) input terminal allocation
(Switching control)
Setting
range
0 to F Unit --- Default
setting
8 Restart
power?
Yes
Operation Chapter 4
