2-27
H Three-phase 200 V: R88D-WT15H (1.5 kW)
D Wall Mounting
5 dia. Four, M4
External dimensions Mounted dimensions
D Front Panel Mounting (Using Mounting Brackets)
Two, 5 dia.
Four, M4
External dimensions Mounted dimensions
Standard Models and Specifications
Chapter 2
