2-26
H Three-phase 200 V: R88D-WT05H/-WT08H/-WT10H (500 W to 1 kW)
D Wall Mounting
5 dia.
Two, M4
External dimensions Mounted dimensions
D Front Panel Mounting (Using Mounting Brackets)
5 dia.
Two, M4
External dimensions Mounted dimensions
Standard Models and Specifications
Chapter 2
