2-30
H Three-phase 200 V: R88D-WT60H/-WT75H (6 to 7.5 kW)
D Wall Mounting
External dimensions
230 max.
Mounting dimensions
230 max.
235 max.
Four, M6
350 max.
350 max.
Two, 7 dia.
180±0.5
355 0.5
±
Standard Models and Specifications
Chapter 2
