2-31
H Three-phase 200 V: R88D-WT150H (15 kW)
D Wall Mounting
External dimensions
Two, 7 dia.
Mounting dimensions
Four, M6
260
200±5
435 0.5
±
Standard Models and Specifications
Chapter 2
