2-46
H 1,500-r/min Servomotors with a Brake
D 200 V AC: 450 W/850 W/1.3 kW/1.8 kW/2.9 kW/4.4 kW
R88M-W45015T-B(S2)/-W85015T-B(S2)/-W1K315T-B(S2)/-W1K815T-B(S2)/
-W2K915T-B(S2)/-W4K415T-B(S2) [Absolute]
Dimensions of output section
of 450-W to 1.3-kW Servomotors
Dimensions of shaft end
with key (-BS2)
M (Effective depth: )
Four, Z dia.
30 dia.
D2 dia.
S dia.
D1 dia.
D3 dia.
Model
Dimensions (mm)
Model
LL LR KB1 KB2 KL1 KL2 C D1 D2 D3 F G Z S QK b h t1 M

R88M-W45015T-Bj
176
58
56 154
120 88 130 145 110h7 165 6 12 9 19h6 25 5 5 3 M5 12
R88M-W85015T-Bj
199
58
79 177
120
88
130
145
110h7
165
6
12
9
19h6
25
5
5
3
M5
12
R88M-W1K315T-Bj
223 103 201 22h6 6 6 3.5
R88M-W1K815T-Bj
217
79
79 195
146 88 180 200
114.3
0
0 025
230 3.2 18 13.5
35
0.01
0
60 10 8 5 M12 25
R88M-W2K915T-Bj
243
79
105 221
146
88
180
200
114
.
3
0
–0.025
230
3.2
18
13.5
35
0
.
01
0
60
10
8
5
M12
25
R88M-W4K415T-Bj
277 139 255
Note The external dimensions are the same for IP67 (waterproof) models (-BOj).
Standard Models and Specifications
Chapter 2
