Omron OMNUC R88D-WT15HF User Manual

2-47
H 1,500-r/min Servomotors without a Brake
D 200 V AC: 5.5 kW/7.5 kW/11 kW/15 kW
R88M-W5K515T(-S2)/-W7K515T(-S2)/-W11K015T(-S2)/-W15K015T(-S2) [Absolute]
Dimensions of shaft end
with key (-S2)
M (Effective depth: )
Four,
Z dia.
D2 dia.
S dia.
D1 dia.
D3 dia.
Dimensions of output
section of 11-kW and
15-kW Servomotors
15 dia.
2
Model
Dimensions (mm)
Model
LL LR KB1 KB2 KL1 KL2 IE C D1 D2 D3 F G Z S QK b h t1 M

R88M-W5K515T-j
260
113
174 238
150 150 123 180 200
114.
3
0
0 025
230 3.2 18 13.5 42h6 90 12 8 5 M16 32
R88M-W7K515T-j
334
113
248 312
150
150
123
180
200
114
.
3
0
–0.025
230
3.2
18
13.5
42h6
90
12
8
5
M16
32
R88M-W11K015T-j
338
116
251 317
168 168
142
220 235 200h7 270 4
18
13.5
42h6
90
12 8 5 M16 32
R88M-W15K015T-j
457
116
343 435
168
168
150
220
235
200h7
270
4
20
13.5
55
0.030
0.011
90
16 10 6 M20 40
Note The external dimensions are the same for IP67 (waterproof) models (Oj).
Standard Models and Specifications
Chapter 2
