2-48
H 1,500-r/min Servomotors with a Brake
D 200 V AC: 5.5 kW/7.5 kW/11 kW/15 kW
R88M-W5K515T-B(S2)/-W7K515T-B(S2)/-W11K015T-B(S2)/-W15K015T-B(S2)
[Absolute]
Dimensions of shaft end
with key (-BS2)
M (Effective depth: )
Four,
Z dia.
D2 dia.
S dia.
D1 dia.
D3 dia.
Dimensions of output
section of 11-kW and
15-kW Servomotors
15 dia.
2
Model
Dimensions (mm)
Model
LL LR KB1 KB2 KB3 KL1 KL2 KL3 IE C D1 D2 D3 F G Z S QK b h t1 M

R88M-W5K515T-Bj
311
113
174 289 231
150 88 123 123 180 200
114.3
0
–0.025
230 3.2 18 13.5 42h6 90 12 8 5 M16 32
R88M-W7K515T-Bj
385 248 363 305
114.3
0
–0.025
R88M-W11K015T-Bj
383
116
258 362 315
168 88 142
142
220 235
200h7
270 4
18
13.5
42h6
90
12 8 5 M16 32
R88M-W15K015T-Bj
519
116
343 497 415
168
88
142
150
220
235
200h7
270
4
20
13.5
55
0.030
0.011
90
16 10 6 M20 40
Note The external dimensions are the same for IP67 (waterproof) models (-BOj).
Standard Models and Specifications
Chapter 2
