24 Frequency inverters
E D1000 kit - DC Supply with Regenerative Active Front End
E R1000 kit - Regenerative Braking unit
Rated power
(kW)
D1000 kit
Regenerative DC bus supply unit
(D1000)
*1
EMC filter
*1
*1. It is not possible to purchase the Regenerative DC bus supply unit (D1000), EMC filter and low harmonic filter as a separate items.
Low harmonic filter
*1
Kit code
5 CIMR-DC4A0005BAA B84143A0020R106 B84143G0008R176 D1KIT40005AAAAB
10 CIMR-DC4A0010BAA B84143G0016R176 D1KIT40010AAAAB
20 CIMR-DC4A0020BAA B84143A0035R106 B84143G0030R176 D1KIT40020AAAAB
30 CIMR-DC4A0030AAA B84143A0065R106 B84143G0043R176 D1KIT40030AAAAB
40 CIMR-DC4A0040AAA B84143G0058R176 D1KIT40040AAAAB
60 CIMR-DC4A0060AAA B84143B0180S080 B84143G0086R176 D1KIT40060AAAAB
100 CIMR-DC4A0100AAA B84143G0145R176 D1KIT40100AAAAB
130 CIMR-DC4A0130AAA B84143B0400S080 B84143G0210S176 D1KIT40130AAAAB
185 CIMR-DC4A0185AAA B84143G0300S176 D1KIT40185AAAAB
270 CIMR-DC4A0270AAA B84143B1000S080 B84143G0410S176 D1KIT40270AAAAB
370 CIMR-DC4A0370AAA B84143G0560S176 D1KIT40370AAAAB
Rated power
(kW)
R1000 kit
Regenerative braking unit (R1000)
*1
*1. It is not possible to purchase the Regenerative braking unit (R1000) and current suppression reactor as a separate items.
Current suppression reactor (1%)
*1
Kit code
3.5 CIMR-RC4A03P5FAA B1509105 R1KIT40003AAAAA
5 CIMR-RC4A0005FAA R1KIT40005AAAAA
7 CIMR-RC4A0007FAA B1509106 R1KIT40007AAAAA
10 CIMR-RC4A0010FAA B1509107 R1KIT40010AAAAA
14 CIMR-RC4A0014FAA B1509108 R1KIT40014AAAAA
17 CIMR-RC4A0017FAA R1KIT40017AAAAA
20 CIMR-RC4A0020FAA B1509109 R1KIT40020AAAAA
28 CIMR-RC4A0028FAA B1509110 R1KIT40028AAAAA
35 CIMR-RC4A0035AAA B1504118 R1KIT40035AAAAA
43 CIMR-RC4A0043AAA B1509111 R1KIT40043AAAAA
53 CIMR-RC4A0053AAA B1509112 R1KIT40053AAAAA
73 CIMR-RC4A0073AAA B1509113 R1KIT40073AAAAA
105 CIMR-RC4A0105AAA B1509114 R1KIT40105AAAAA
150 CIMR-RC4A0150AAA B1505002 R1KIT40150AAAAA
210 CIMR-RC4A0210AAA B1505008 R1KIT40210AAAAA
300 CIMR-RC4A0300AAA B1505011 R1KIT40300AAAAA
