Regular Payload Series-Hardware Installation Manual TM5 Series Hardware Version: 3.2 26
Figure 12: Assembly of TM5X-900
4.2.1.3 Range of Motion
The working spherical (radius) range from the base is 700 mm for the TM5-700 series and 900 mm for
the TM5-900 series.
TM5X-900
