4-57
4-2 Function Mode
4
Functions
User Parameter Automatic Setting Function
•When user parameter automatic setting function b039 is set to "01" (enabled), the parameters
subjected to a data change are automatically stored in sequence (from U001 to U012). This data
can be used as changed data.
•The screen information is stored when the Enter key is pressed. The monitor screens (d***) are
also stored in the same manner.
•U001 is the most recent parameter, and U012 is the oldest.
•The same parameter cannot be stored. If the number of parameters stored exceeds 12, the oldest
data (U012) is erased.
Torque Limit Function
•This function limits motor output torque when "03" (sensorless vector control), "04" (0-Hz
sensorless vector control), or "05" (sensor vector control) is selected in control method A044/A244.
Parameter No. Function name Data Default setting Unit
b039
User parameter automatic
setting function selection
00: Disabled
01: Enabled
00 
Related functions U001 to U012
Parameter No. Function name Data Default setting Unit
A044/A244
V/f characteristics
selection
03: Sensorless vector
04: 0-Hz sensorless vector
05: Sensor vector (A244 is blank.)
00 
b040 Torque limit selection
00: Four-quadrant separate setting
01: Terminal switch
02: Analog input
03: Option 1
04: Option 2
00 
b041 Torque limit 1
0. to 200. (0.4 to 55 kW)
0. to 180. (75 to 132 kW)
Forward power running
under four-quadrant separate setting
150. %
b042 Torque limit 2
0. to 200. (0.4 to 55 kW)
0. to 180. (75 to 132 kW)
Reverse regeneration
under four-quadrant separate setting
150. %
b043 Torque limit 3
0. to 200. (0.4 to 55 kW)
0. to 180. (75 to 132 kW)
Reverse power running
under four-quadrant separate setting
150. %
b044 Torque limit 4
0. to 200. (0.4 to 55 kW)
0. to 180. (75 to 132 kW)
Forward regeneration
under four-quadrant separate setting
150. %
C001 to C008
Multi-function inputs
1 to 8 selection
40: Torque limit enabled
41: Torque limit switching 1
42: Torque limit switching 2

C021 to C025
Multi-function output
terminal selection
10: During torque limit 
Related functions A044, A244, C001 to C008
