Omron RX - Standard Specification List

7-1
7-1 Standard Specification List
7
Specifications
7Specifications
7-1 Standard Specification List
Three-phase 200-V Class
Class 3-phase 200 V
Model name (RX-) A2004 A2007 A2015 A2022 A2037 A2055 A2075 A2110 A2150 A2185 A2220
Max.
applicable
motor 4P
kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
Rated output
capacity (kVA)
200 V 1.0 1.7 2.5 3.6 5.7 8.3 11.0 15.9 22.1 26.3 32.9
240 V 1.2 2.0 3.1 4.3 6.8 9.9 13.3 19.1 26.6 31.5 39.4
Rated input voltage 3-phase (3-wire) 200 V -15% to 240 V +10%, 50/60 Hz ±5%
Rated output voltage 3-phase: 200 to 240 V (Cannot exceed that of incoming voltage.)
Rated output current (A) 3.0 5.0 7.5 10.5 16.5 24 32 46 64 76 95
Radio noise filter Built-in
Weight (kg) 3.5 3.5 3.5 3.5 3.5 6 6 6 14 14 14
Braking
Regenerative
braking
Built-in braking resistor circuit (discharge resistor separately mounted)
Minimum
connection
resistance ()
50 50 35 35 35 16 10 10 7.5 7.5 5
Class 3-phase 200 V
Model name (RX-) A2300 A2370 A2450 A2550
Max.
applicable
motor 4P
kW 30 37 45 55
Rated output
capacity (kVA)
200 V 41.9 50.2 63.0 76.2
240 V 50.2 60.2 75.6 91.4
Rated input voltage
3-phase (3-wire) 200 V -15% to
240 V +10%, 50/60 Hz ±5%
Rated output voltage
3-phase: 200 to 240 V (Cannot
exceed that of incoming
voltage.)
Rated output current (A) 121 145 182 220
Radio noise filter Built-in
Weight (kg) 22 30 30 43
Braking
Regenerative
braking
Regenerative braking unit
separately mounted
Minimum
connection
resistance ()

