4-94
4-2 Function Mode
4
Functions
Multi-function Output Terminal Contact Selection
•You can set NO- or NC-contact output individually for multi-function output terminals 11 to 15 as
well as the relay output terminal.
•Multi-function output terminals 11 to 15 provide open-collector output.
33 LOG1: Logic operation output 1
Logic operation function 4-100
34 LOG2: Logic operation output 2
35 LOG3: Logic operation output 3
36 LOG4: Logic operation output 4
37 LOG5: Logic operation output 5
38 LOG6: Logic operation output 6
39 WAC: Capacitor life warning signal Capacitor life warning signal 4-101
40 WAF: Cooling fan life warning signal Cooling fan speed drop signal 4-102
41 FR: Starting contact signal Starting contact signal 4-103
42 OHF: Fin overheat warning Fin overheat warning 4-103
43 LOC: Light load detection signal Light load detection signal 4-104
44 Not used

45 Not used
46 Not used
47 Not used
48 Not used
49 Not used
50 IRDY: Operation ready signal Operation ready signal 4-104
51 FWR: Forward run signal Forward run signal 4-104
52 RVR: Reverse run signal Reverse run signal 4-105
53 MJA: Fatal fault signal Fatal fault signal 4-105
54 WCO: Window comparator O
Window comparator function 4-6355 WCOI: Window comparator OI
56 WCO2: Window comparator O2
Related functions C021 to C025, C026
Data Description Reference item Page
Parameter No. Function name Data Default setting Unit
C031 to C035
Multi-function output
terminal contact selection
00: NO contact
01: NC contact
00 
C036
Relay output (AL2, AL1)
contact selection
00: NO contact between AL2 and AL0
01: NC contact between AL2 and AL0
01 
