4-150
4-4 Communication Function
4
Functions
•Transmission frame
Frame format
STX Station No. Command BCC CR
Description Data size Setting
STX Control code (Start of TeXt) 1 byte STX (0x02)
Station No. Station No. of the target Inverter 2 bytes 01 to 32
Command Transmission command 2 bytes 05
BCC Block check code 2 bytes
Exclusive OR from station No. to
data. (Refer to page 4-157.)
CR Control code (Carriage Return) 1 byte CR (0x0D)
To Next Page
