4-175
4-4 Communication Function
4
Functions
Inverter Trip Factor List
003Ah Fault monitor 5 factor
d085 R
See "Inverter Trip Factor List"
(page 4-175).

003Bh Fault monitor 5 Inverter status
See "Inverter Trip Factor List"
(page 4-175).

003Ch Fault monitor 5 frequency (HIGH)
0 to 40000
0.01
[Hz]
003Dh Fault monitor 5 frequency (LOW)
003Eh Fault monitor 5 current
Output current value at the time of
tripping
0.1 [A]
003Fh Fault monitor 5 voltage DC input voltage at the time of tripping 1 [V]
0040h Fault
monitor 5 RUN time (HIGH)
Total RUN time before the trip 1 [h]
0041h Fault monitor 5 RUN time (LOW)
0042h Fault monitor 5 ON time (HIGH)
Total power ON time before the trip 1 [h]
0043h Fault monitor 5 ON time (LOW)
0044h Fault monitor 6 factor
d086 R
See "Inverter Trip Factor List"
(page 4-175).

0045h Fault monitor 6 Inverter status
See "Inverter Trip Factor List"
(page 4-175).

0046h Fault monitor 6 frequency (HIGH)
0 to 40000
0.01
[Hz]
0047h Fault monitor 6 frequency (LOW)
0048h Fault monitor 6 current
Output current value at the time of
tripping
0.1 [A]
0049h Fault monitor 6 voltage DC input voltage at the time of tripping 1 [V]
004Ah Fault monitor 6 RUN time (HIGH)
Total RUN time before the trip 1 [h]
004Bh Fault
monitor 6 RUN time (LOW)
004Ch Fault monitor 6 ON time (HIGH)
Total power ON time before the trip 1 [h]
004Dh Fault monitor 6 ON time (LOW)
004Eh Warning monitor d090 R Warning code 
004Fh
to
08FFh
Not used  
0900h EEPROM write  W
0000: Motor parameter recalculation
0001: Set value storage in EEPROM
Other: Motor parameter recalculation
and set value storage in
EEPROM

0901h
to
1000h
Not used  
Register
No.
Function name
Function
code
R/W Monitor and setting parameters Resolution
Note 1: The Inverter's rated current is "1000".
Note 2: If the set value is "10000" (100.0 sec) or more, the value in the second decimal place is ignored.
Trip factor high-order (factor) Trip factor low-order (Inverter status)
Name Code Name Code
No trip factor 0 During reset 0
