2-2 Wiring
2
Design
*1. When the cable is connected without using the crimp terminal (bare wires), use the square washer included
with the product.
Note: The cable size is based on the HIV cable (75C heat resistance).
400-V class
0.4 RX-A4004 1.25 1.25 1.25 M4 1.25-4
1.2
(max.1.8)
5 A
0.75 RX-A4007 1.25 1.25 1.25 M4 1.25-4
1.2
(max.1.8)
5 A
1.5 RX-A4015 2 2 2 M4 2-4
1.2
(max.1.8)
10 A
2.2 RX-A4022 2 2 2 M4 2-4
1.2
(max.1.8)
10 A
3.7 RX-A4037 2 2 2 M4 2-4
1.2
(max.1.8)
15 A
5.5 RX-A4055 3.5 3.5 3.5 M5 R2-5
2.4
(4.0 max.)
30 A
7.5 RX-A4075 3.5 3.5 3.5 M5 3.5-5
2.4
(4.0 max.)
30 A
11 RX-A4110 5.5 5.5 5.5 M6 R5.5-6
4.5
(4.4 max.)
50 A
15 RX-A4150 8 8 8 M6 8-6
4.5
(4.9 max.)
60 A
18.5 RX-A4185 14 14 14 M6 14-6
4.5
(4.9 max.)
60 A
22 RX-A4220 14 14 14 M6 14-6
4.5
(4.9 max.)
75 A
30 RX-A4300 22 22 - M6 22-6
4.5
(4.9 max.)
100 A
37 RX-A4370 38 22  M8
*1
38-8
8.1
(20.0 max.)
100 A
45 RX-A4450 38 22  M8
*1
38-8
8.1
(20.0 max.)
150 A
55 RX-A4550 60 30  M8
*1
R60-8
8.1
(20.0 max.)
175 A
75 RX-B4750
100
(38 x 2)
38  M10
*1
100-10
20.0
(22.0 max.)
225 A
90 RX-B4900
100
(38 x 2)
38  M10
*1
100-10
20.0
(22.0 max.)
225 A
110
RX-
B411K
150
(38 x 2)
60  M10
*1
150-10
20.0
(35.0 max.)
350 A
132
RX-
B413K
80 x 2
80
 M10
*1
80-10
20.0
(35.0 max.)
350 A
Motor
output
(kW)
Applicable
Inverter
model
Power cable
(mm
2
)
R, S, T, U, V,
W, PD/+1,
P/+, N/-
Ground
cable
(mm
2
)
External
braking resistor
between PD/+1
and RB (mm
2
)
Terminal
screw
size
Crimp
terminal
Tightening
torque
N•m
Applicable
device
Earth leakage
breaker (ELB)
