2-22
2-2 Wiring
2
Design
 Selecting the Sequence Input Method (Sink/Source Logic)
 Selecting the Sequence Output Method (Sink/Source Logic)
When the Inverter's internal interface power supply is
used
When external power supply is used
(Remove the short-circuit bar from the control
terminal block.)
Sink logicSource logic
P24+V
CM1
PLC
FW
8
24 V DC
Inverter
Short-circuit
bar
COM
Output unit etc.
P24+V
CM1
PLC
FW
8
24 V DC
Inverter
COM
DC24V
Output unit etc.
P24
CM1
PLC
FW
8
0V
Output unit etc.
24 V DC
Inverter
Short-circuit
bar
COM
P24
CM1
PLC
FW
8
0V
Output unit etc.
24 V DC
Inverter
COM
24 V DC
Sink logic
Source logic
11
24 V DC
Inverter
COM
CM2
12
11
24 V DC
Inverter
COM
CM2
12
