108
Frame Structure Section 7-2
Parameters
■ Variable Type 81
Address Name Data range
0000 Undervoltage alarm value 00B4 to 0108 (18.0 to 26.4 V)
0001 Overvoltage alarm value 00C8 to 0120 (20.0 to 28.8 V)
0002 Over-temperature output value 0019 to 0050 (25 to 80°C)
0003 Run time value 0001 to 03E7 (1 to 99.9 kh)
0004 Protection level 0000 to 0002
(0: R/W allowed; 1: Limited R/
W; 2: Limited read-only)
Address Name Data range
0010 Current tripping type for branch output 1 0000 or 0001
(0: Standard; 1: Instanta-
neous)
0011 Current tripping type for branch output 2
0012 Current tripping type for branch output 3
0013 Current tripping type for branch output 4
Address Name Data range
0020 Current tripping value for branch output 1 0005 to 0028 (0.5 to 4.0 A)
UL Class 2 output model:
0005 to 0026 (0.5 to 3.8 A)
0021 Current tripping value for branch output 2
0022 Current tripping value for branch output 3
0023 Current tripping value for branch output 4
Address Name Data range
0030 Overcurrent alarm type for branch output 1 0000 or 0001 (0: Standard; 1:
Instantaneous)
0031 Overcurrent alarm type for branch output 2
0032 Overcurrent alarm type for branch output 3
0033 Overcurrent alarm type for branch output 4
Address Name Data range
0040 Overcurrent alarm value for branch output
1
0005 to 0028 (0.5 to 4.0 A)
UL Class 2 output model:
0005 to 0026 (0.5 to 3.8 A)
0041 Overcurrent alarm value for branch output
2
0042 Overcurrent alarm value for branch output
3
0043 Overcurrent alarm value for branch output
4
Address Name Data range
0050 Startup sequence for branch output 1 0000 to 03E7
(0: Disabled, or 0.1 to 99.9 s)
0051 Startup sequence for branch output 2
0052 Startup sequence for branch output 3
0053 Startup sequence for branch output 4
Address Name Data range
0060 Shutdown sequence for branch output 1 0000 to 03E7 (0: Disabled, or
0.1 to 99.9 s)
0061 Shutdown sequence for branch output 2
0062 Shutdown sequence for branch output 3
0063 Shutdown sequence for branch output 4
