Slave address for ICs (8bits) list
IC Slave Address 詳細
DSP 82 DSP data
EEPROM 62 The Virtual EEPROM zone for currently selected DSP preset
mode of Preset 0 to Preset 7
EEPROM 90 The EEPROM zone for Preset 0 DSP data
EEPROM 91 The EEPROM zone for Preset 1 DSP data
EEPROM 92 The EEPROM zone for Preset 2 DSP data
EEPROM 93 The EEPROM zone for Preset 3 DSP data
EEPROM 94 The EEPROM zone for Preset 4 DSP data
EEPROM 95 The EEPROM zone for Preset 5 DSP data
EEPROM 96 The EEPROM zone for Preset 6 DSP data
EEPROM 97 The EEPROM zone for Preset 7 DSP data
uCOM 22 The uCOM data
EEPROM 42 The EEPROM zone for uCOM Data
Note: There is maximum number of writing to EEPROM of 1,000,000 times.
Error code list
If an error occurs, camera sends an error code with following format:
The Command number of Error Message is FF (HEX). The Data length is 0002.
Error Receive data
Last data that camera was received was not ETX (0x03) 02, FF, 00, 02, 02, 00, 03, 03
Check sum does NOT match data being transmitted 02, FF, 00, 02, 03, 00, 04, 03
The command being transmitted does NOT exist or is invalid 02, FF, 00, 02, 04, 00, 05, 03
Unprocessed data remains in receiving buffer 02, FF, 00, 02, 05, 00, 06, 03
Time out 02, FF, 00, 02, 06, 00, 07, 03
Over run error 02, FF, 00, 02, 08, 00, 08, 03
Data length error (too long) 02, FF, 00, 02, 0B, 00, 0C, 03
I2C communication error 02, FF, 00, 02, 10, 00, 11, 03
Note.1: The camera disregards data, which is not start with STX (0x02).
Note.2: The time out error is occurred when camera does not receive next data 3 seconds after receiving
data.
