Omron STC-HD213 Series - Specifications Overview; Electronic Specifications

No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
’
s Guide
9/94
4 Specifications
4.1 Electronic specifications
STC-HD213DV / STC-HD213DV-CS / STC-HD213DVN / STC-HD213DVN-CS
Default: Bold
Model Number STC-HD213DV / STC-HD213DV-CS STC-HD213DVN / STC-HD213DVN-CS
Image Sensor 1/2.8" 2M Progressive Color CMOS (SONY: IMX291)
Shutter Type Rolling Shutter
HD Active Picture Elements 1,920 (H) x 1,080 (V)
Cell Size 2.9 (H) x 2.9 (V) µm
Sync. System Internal
Video Output DVI 1.0 conformity RGB
1080p60 / 1080p59.94 / 1080p50 / 1080p30 / 1080p25 / 1080i60 / 1080i59.94 / 1080i50 /
720p60 / 720p59.94 / 720p50 / Auto
Minimum Scene Illumination 0.4 Lux (Maximum Gain) @ F1.4
Camera Functions
ALC AEE (auto exposing) and AGC are configurable via UART communication (Default: ALC On)
Shutter Speed AEE or fixed exposure time control is selectable via UART communication (Default: AEE)
Extended Extend shutter frame unit (Up to 2.12 seconds) N/A
High Speed From 1/33,750 seconds (*1)
Gain AGC or Fixed gain is selectable via UART communication (Default: AGC)
0 to 45 dB
Gamma Gamma is selectable from manual and 8 preset (0.3 / 0.45 / 0.5 / 0.6 / 0.7 / 0.8 / 0.9 / 1)
via UART communication (Default: Manual)
White Balance Auto white balance / Manual white balance / Push to set white balance
White balance is selectable via UART (Default: Auto white balance)
WDR N/A
Mirror Image Horizontal flip / Vertical flip / Horizontal and vertical flip (180-degree rotation) / Normal image
(Default: Normal image)
DSP user Preset 8 User preset is selectable via UART communication (Default: Preset 0)
Line Generator Four lines (Two horizontal and two vertical lines with all available colors)
(Default: Disable)
Circle Line
Generator
One circle
(Default: Disable)
Shadow Mask
Generator
Both horizontal and vertical with shading level are adjustable via UART communication
(Default: Disable)
Still Image Live video or freeze image is selectable
via UART communication
(Default: Live video)
N/A
Digital Zoom Support N/A
Communication +3.3V UART communication via 3.5Φ Stereo Jack
(Baud rate: 115,200ps / 57,600bps / 38,400bps / 19,200bps / 9,600bps)
Character
Generator
Built-in character generation function via UART communication
Defective Pixel
Collection
Support (Up to 256 points)
Power Input Voltage +9 to +15 Vdc (Typical: +12 Vdc)
Consumption Less than 3.2 W Less than 2.1 W
