No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
81/94
Address
7
6
5
4
3
2
1
0
Descriptions Default
00A X
X
X
X
X
X
X
X
AEE maximum exposure time [little-endian] * Two’s compliment
-447 to 561
* 0 to 561 for STC-HD213DVN, HD213DNV-CS, HD213SDIN
and HD213SDIN-CS
0
00B X
X
X
X
X
X
X
X
00C X
X
X
X
X
X
X
X
Brightness tolerance for AEE control
The auto exposing control is stopped when differences between
“target brightness” and current brightness of image is smaller
than this value.
3
00D X
X
X
X
X
X
X
X
Brightness threshold for AEE control
The auto exposing control is starting when differences between
“target brightness” and current brightness of image is greater
than “tolerance + threshold”.
6
00E 0
X
X
X
X
X
X
X
AEE control speed
The maximum change of exposure time for auto exposing control
is limit by this value.
* There is not limit when setting 0
0
00F X
X
X
X
X
X
X
X
Reserved -
The relationship between setting and exposure time
The relationship between setting and exposure time is changing based by selected “Resolution / frame rate”
setting
[0x060]
* The range of setting for STC-HD213DVN, HD213DVN-CS, HD213SDIN and HD213SDIN-CS is “0 to 561”.
60 fps frame rate
Setting Exposure time Setting Exposure time
0 16.64 [msec.]
1/60.1 [sec.]
-64 33.3 [msec.]
1/30 [sec.]
225 9.99 [msec.]
1/100.1 [sec.]
-128 66.7 [msec.]
2/30 [sec.]
281 8.33 [msec.]
1/120.1 [sec.]
-192 133.3 [msec.]
4/30 [sec.]
393 5.01 [msec.]
1/199.7 [sec.]
-256 266.7 [msec.]
8/30 [sec.]
450 3.32 [msec.]
1/301.3 [sec.]
-320 533.3 [msec.]
16/30 [sec.]
495 1.99 [msec.]
1/503.7 [sec.]
-384 1.07 [sec.]
32/30 [sec.]
561 29.6 [usec.]
1/33,750
[sec.]
-447 2.12 [sec.]
64/30 [sec.]
50 fps frame rate
Setting Exposure time Setting Exposure time
0 19.96 [msec.]
1/50.1 [sec.]
-64 40.0 [msec.]
1/25 [sec.]
281 9.99 [msec.]
1/100.1 [sec.]
-128 80.0 [msec.]
2/25 [sec.]
328 8.32 [msec.]
1/120.2 [sec.]
-192 160.0 [msec.]
4/25 [sec.]
421 5.01 [msec.]
1/199.5 [sec.]
-256 320.0 [msec.]
8/25 [sec.]
450 3.98 [msec.]
1/251.1 [sec.]
-320 640.0 [msec.]
16/25 [sec.]
506 1.99 [msec.]
1/502.2 [sec.]
-384 1.28 [sec.]
32/25 [sec.]
561 35.6 [usec.]
1/28,125
[sec.]
-447 2.56 [sec.]
64/25 [sec.]
To Next Page
