No. 20S071-01
STC-HD213DV / STC-HD213DV-CS / STC-HD213SDI / STC-HD213SDI-CS /
STC-HD213DVN / STC-HD213DVN-CS / STC-HD213SDIN / STC-HD213SDIN-CS
Product Specifications and User
86/94
Address
7
6
5
4
3
2
1
0
Descriptions Default
060 0
0
0
0
X
X
X
X
Resolution/Frame Rate
0: 1080p 60fps 1: 1080p 30fps
2: 1080i 60fps 3: 1080p 50fps
4: 1080pP 25fps 5: 1080i 50fps
6: 720p 60fps 7: 720p 50 fps
8: 1080p 59.94fps 9: 1080p 29.97fps
10: 1080i 59.94fps 11: 720p 59.94fps
12: Auto
* Auto is only available for DVI output models.
(When selecting “Auto”, resolution/frame rate is selecting
automatically based on connected monitor supports)
0
061 X
Horizontal image flip
0: OFF (No flip)
1: ON (horizontal flipped image)
0
X
Vertical image flip
0: OFF (No flip)
1: ON (vertical flipped image)
X
X
X
X
X
X
Reserved -
062 X
X
X
X
X
X
X
X
Reserved -
063 X
X
X
X
Preset gamma selection
0: 1.0 1: 0.9
2: 0.8 3: 0.7
4: 0.6 5: 0.5
6: 0.45 7: 0.3
9: Through
* Selected preset gamma is valid when selecting “Preset gamma”
at “Gamma mode”
0
X
X
X
Reserved -
X
Gamma Mode
0: Preset gamma 1: Manual
1
X
X
X
Reserved -
064 X
X
X
X
X
X
X
X
Manual Gamma 0 [little-endian] * Two’s compliment 0
065 0
0
0
0
0
0
X
X
066 X
X
X
X
X
X
X
X
Manual Gamma 1 [little-endian] * Two’s compliment 68
067 0
0
0
0
0
0
X
X
068 X
X
X
X
X
X
X
X
Manual Gamma 2 [little-endian] * Two’s compliment 130
069 0
0
0
0
0
0
X
X
06A X
X
X
X
X
X
X
X
Manual Gamma 3 [little-endian] * Two’s compliment 159
06B 0
0
0
0
0
0
X
X
06C X
X
X
X
X
X
X
X
Manual Gamma 4 [little-endian] * Two’s compliment 181
06D 0
0
0
0
0
0
X
X
06E X
X
X
X
X
X
X
X
Manual Gamma 5 [little-endian] * Two’s compliment 200
06F 0
0
0
0
0
0
X
X
070 X
X
X
X
X
X
X
X
Manual Gamma 6 [little-endian] * Two’s compliment 220
071 0
0
0
0
0
0
X
X
To Next Page
