Omron SYSDRIVE 3G3EV-A-CUE - Specifications of Main Unit

4-2
4-1 Specifications of Main Unit
H Ratings
Model 3G3EV- A2001(M)-
CUE
A2002(M)-
CUE
A2004(M)-
CUE
A2007(M)-
CUE
A2015(M)-
CUE
Three
phase,
Power
supply
Rated voltage and
frequency
Three-phase, 200 to 230 VAC, 50/60 Hz
p,
200 VAC
pp y
Allowable voltage
fluctuation
–15% to 10 %
Allowable
frequency
fluctuation
±5%
Heating value (W) 11.9 18.8 33.2 51.7 71.6
Weight (kg) 0.5 0.6 0.9 1.3 1.5
Maximum applicable motor capacity
(kW)
0.1 0.2 0.4 0.75 1.5
Output
ifi
Rated output capacity (kVA) 0.3 0.6 1.1 1.9 2.7
p
specifi-
cations
Rated output current (A) 0.8 1.5 3.0 5.0 7.0
cat
i
ons
Rated output voltage Three-phase, 200 to 230 VAC (Corresponds to the input
voltage)
Maximum output frequency 400 Hz (Parameter setting)
Cooling method Self-cooling
Model 3G3EV- AB001(M)-
CUE
AB002(M)-
CUE
AB004(M)-
CUE
AB007(M)-
CUE
AB015(M)
-CUE
Single
phase/
Power
supply
Rated voltage and
frequency
Single-phase/Three-phase, 200 to 240 VAC, 50/60 Hz
p/
Three
phase,
200 VAC
pp y
Allowable voltage
fluctuation
–15% to 10 %
200 VAC
Allowable
frequency
fluctuation
±5%
Heating value (W) 12.6 20.3 25.3 55.3 78.4
Weight (kg) 0.5 0.6 1.3 1.3 2.0
Maximum applicable motor capacity
(kW)
0.1 0.2 0.4 0.75 1.5
Output
ifi
Rated output capacity (kVA) 0.3 0.6 1.1 1.9 2.7
p
specifi-
cations
Rated output current (A) 0.8 1.5 3.0 5.0 7.0
cat
i
ons
Rated output voltage Three-phase, 200 to 230 VAC (Corresponds to the input
voltage)
Maximum output frequency 400 Hz (Parameter setting)
Cooling method Self-cooling
Note Model numbers with a suffix of “-CUE” indicate models approved by UL. (Approval has not been
obtained for models with a model number suffix of “-CE.”)
Specifications Chapter 4
