7. Connection Procedure
7.3.2. Opening the Project File and Connecting Online with PLC
Start the CX-Programmer, read the project file and connect online with the PLC.
Install the CX-Programmer and USB driver in the personal computer beforehand.
1
Confirm that the PC and PLC
are connected with the USB
cable and turn ON the power
supply to the PLC.
Start the CX-Programmer.
*If a confirmation dialog for an
access right is displayed at
start, select to start.
2
Select Open from the File Menu.
3
On the Open CX-Programmer
Project Dialog Box, select the
OMRON_V750_PMCR232C_E
V102.cxp.cxp and click the
Open Button.
*Obtain the project file from
OMRON.
4
After opening the project file,
select Programs in the project
workspace.
(Project workspace)
21
To Next Page
