7. Connection Procedure
5
Select Change Model from the
PLC Menu.
6
The Change PLC Dialog Box is
displayed. Select a device type
of the PLC to use from the
pull-down list in the Device
Type, and click the Settings
Button.
*CJ2M is selected in this
document.
7
The Device Type Settings Dialog
Box is displayed. Select a CPU
type to use from the pull-down
list in the CPU Type, and click
the OK Button.
*CPU12 is selected in this
document.
22
To Next Page
