7. Connection Procedure
37
ol Macro Data
T o the Serial Communications Unit.
7.3.7. Transferring the Protoc
ransfer the protocol macro data t
1
Double-click the New Protocol
List on the project workspace to
open the tre
e.
2
The Project Window on the right
is displayed. Confirm that
SCU[0] was entered in the
Target Column.
*If SCU[0] is not entered, select
SCU[0] as shown in the right
figure.
3
Select New Protocol List and
select Download Protocols
from the Protocol Menu.
4
The dialog box on the right is
displayed. Select the Include
Source Information Check Box
and click the Compile Button.
To Next Page
