7. Connection Procedure
41
5
Select the Trace 2 icon ( ) on
*Trace 2 corresponds to port 2
of the Serial Communications
the Project Windo
w.
(Confirm that Trace 2 is
highlighted as shown on the
right figure.)
Unit.
6
Select Start Trace - One Shot
Trace from the PLC Menu.
7
Confirm that t
2 in the Projec
he status of Trace
t Window was
unning.
changed to One-shot Trace
R
