7. Connection Procedure
4
Select Monitor from the Online
Menu.
5
The Monitor Memory Areas Dialog
Box is displayed.
Select the CIO
click the Monitor
Check Bo
x and
Button.
6
On the CIO Window shown on the
right, check the received data
(identification code).
(In the right example, the data
stored in CIO 5510 onwards are
t
those in step 3 of Section 7.4.3. )
*In CIO 5500, the number of used
words (18 words (24 in decimal) is
stored. The product type is stored
in CIO5510 to CIO5517 and the
version is stored in CIO5520 to
CIO5523.
*For details, refer to 9.2.2 PMCR
Instruction Operand Settings.
“V750-BA50C04-US” (produc
type) and “102-102-103-0”
(version). These data the same as
45
Product type: ASCII code from CIO5510
“563
7 3530 2D42 4135 3043 3034 2055 53”
(V750-BA50C04-US)
Version: BCD value from CIO5520
“0102 0102 0103 0000” (102-102-103-0)
